Starting with Windows 8.1 (and Server 2012 R2) Microsoft introduced a feature termed LSA Protection. This feature is based on the Protected Process Light (PPL) technology which is a defense-in-depth security feature that is designed to “prevent non-administrative non-PPL processes from accessing or tampering with code and data in a PPL process via open process functions”.
I’ve noticed there is a common misconception that LSA Protection prevents attacks that leverage SeDebug or Administrative privileges to extract credential material from memory, like Mimikatz. LSA Protection does NOT protect from these attacks, at best it makes them slightly more difficult as an extra step needs to be performed.
To bypass LSA Protection you have a few options:
The latter 2 methods require the ability to read and write kernel memory. The easiest method to achieve this will be through loading a driver, although you can create your own I’ve decided to leverage the RTCore64.sys driver from the product MSI Afterburner. I chose this driver because it's signed and allows reading and writing arbitrary memory, thanks MSI.
I decided to implement the 2nd method since removing the PPL flags allows the usage of already established tools like Mimikatz to dump the credential material from LSASS. To do this we need to find the address of the LSASS EPROCESS structure and patch the 5 values: SignatureLevel, SectionSignatureLevel, Type, Audit, and Signer to zero.
The EnumDeviceDrivers function can be used to leak the kernel base address. This can be used to locate the PsInitialSystemProcess which points to the EPROCESS structure for the system process. Since the kernel stores processes in a linked list, the ActiveProcessLinks member of the EPROCESS structure can be used to iterate the linked list and find LSASS.
If we look at the EPROCESS structure (see Figure 2 below) we can see that the 5 fields we need to patch are all conventionally aligned into a continuous 4bytes. This lets us patch the EPROCESS structure in a single 4 byte write like so:
WriteMemoryPrimitive(Device, 4, CurrentProcessAddress + SignatureLevelOffset, 0x00);
Now that the PPL has been removed, all the traditional methods of dumping LSASS will work, such as MimiKatz, the MiniDumpWriteDump API call, etc.
The tool which is written in C/C++ to perform this attack can be found on GitHub. I’ve only tested on Windows 1903, 1909 and 2004. It should work on all versions of Windows since the feature was introduced but I’ve only got the offsets for those versions implemented.
Using the tool
Zeek, formally known as bro, is a high-level packet analysis program. It originally began development in the 1990s and has a long history. It does not directly intercept or modify traffic, rather it passively observes it and creates high-level network logs. It can be used in conjunction with a SIEM to allow quick analysis. It can operate in realtime to create logs of a currently active system, or as a post-mortem analysis tool of a packet capture. This tool can also operate with
Creating a script
While zeek does have some good documentation online, it is definitely lacking in any sort of tutorial-based content for beginners. This is especially true for anyone who wants to try their hand at using zeek scripting language to create a custom plugin.
A simplified understanding of what a signature detection based zeek plugin has to do is:
Importing necessary protocols and defining the module
Here we define the module as
Defining log file
To define the log file there needs to be a log identifier, in this case a
Defining notice type
Zeek allows plugins to define a different Notice type that can be used when generating emails. There are a lot of pre-defined notices that can be used and they are indexed here.
Zeek provides a pattern type that can be used to quickly define multiple regex patterns. The language also has some pattern specific operations such as
When initializing zeek there are a few different methods of recording events. In this case a dedicated log file was chosen. To create this log stream based on the log specifications
Creating an event listener
The netscalard exploit uses a
After running this script against the local interface for testing with the following command:
There are some log files generated. Once a malicious packet has been detected, in this case triggered from a curl command, then a new
Using this plugin post-mortem analysis can also be performed. An example command for this is shown below:
In a recent engagement I had to compromise a hardened desktop running CrowdStrike and Symantec Endpoint Protection. The initial code execution method was my reliable favorite MSBuild (C:\Windows\Microsoft.NET\Framework64\v4.0.30319\MSBuild.exe) which could be leveraged to execute C# code as an inline task.
Initially I wrote a very basic loader that used a bruteforce decryption algorithm to run a Cobalt Strike beacon using VirtualAlloc and CreateThread.
The shellcode was stored encrypted within the C# code and decrypted using a multibyte XOR key with the last 3 bytes removed. The while loop continuously increments the decryption key, performs XOR decryption and hashes the decrypted payload until the hash value of the decrypted shellcode matches its original hash value. This methods prevents antivirus or snooping eyes from easily reading the shellcode, and in fact no antivirus product would spend the amount of time required to decrypt the shellcode even if they knew how to run C# code in MSBuild project files.
CrowdStrike detected and prevented the VirtualAlloc/CreateThread method and classified it as “Process Hollowing”.
I'd never seen that technique detected before, but had been waiting for the day. I knew I’d have to take CrowdStrike seriously and wrote a new loader that used the same decryption routine but now executed code using the undocumented NtMapViewOfSection and NtQueueApcThread functions.
The NtMapViewOfSection routine maps a view of a section object into the virtual address space of a subject process.
The NtQueueApcThread routine adds a user-mode asynchronous procedure call (APC) object to the APC queue of the specified thread.
These methods are far less common, and considered more stealthy. The majority of the loader code was taken from the Sharp-Suite UrbanBishop POC (https://github.com/FuzzySecurity/Sharp-Suite) which implemented exactly what I wanted. I updated the POC slightly to support inline shellcode and automatic process selection for the injection.
The loader now successfully bypassed the CrowdStrike prevention rules. The use of MSBuild did trigger a detection alert in this particular configuration that was unfortunately unavoidable unless a different initial code execution method was used. The detection alert was not a prevention which meant the shell was allowed to live.
The loader does create a suspended thread in the remote process to queue the APC. This can be avoided by selecting an already existing thread, however the thread needs to enter/be in an alertable state for the APC to execute and picking the wrong thread can impact the stability of the remote process. The trade-off for that extra bit of stealthiness did not seem worthwhile but I figured I'd mention it for anyone writing detections.
Introduction to Cutter
Cutter is a Graphical User Interface (GUI) built around the long-lived radare2 disassembler. The largest problem with radare2 is it's usability. Whilst radare is efficient to use once mastered, it has many problems for first time users. Running
Cutter has succeeded in porting radare's fantastic capability into a graphical interface that can compete with the likes of Hopper, IDA, BinaryNinja and Ghidra all while remaining completely free. It also has the added benefit of being multi-platform.
The General Interface
Opening a Binary
When Cutter first launches up you are presented with the below menu that provides a short history of previously opened files, as well as a way to select files from disk.
In radare2, there are different analysis levels that can be appropriate for different circumstances. Since most CTF binaries are usually relatively small, the default option works fine.
Getting a graph view
Once inside the Cutter project view, the differing panes allow you to see quickly the different parts of the code, and all panes can be resized, moved or closed at will. One of these views in particular, the graph view, is very reminiscent of BinaryNinja and contains the logical flow of the program. When clicking through the different functions in the functions panel the hexdump, dissassembly, decompiler and graph view will all be updated in real time. My personal favourite when trying to figure out different sections of the code is to have the functions on the left, graph view in the middle and Decompiler on the right.
Completing a basic PicoCTF Challenge
To show the basic functionality and usage of the tool I will quickly run through a picoCTF reversing challenge from 2018 titled “be quick or be dead 1”.
Executing the binary
The first step is to investigate the binary to see what file type it is, and then execute it.
Since this is an ELF binary I can run it in my linux environment after giving it the executable flag with
Opening it with Cutter
Now that we know the binary has some sort of check preventing us from receiving the flag, we can open it up with cutter.
When opening it I use the default analysis level.
Once cutter is open we are greeted with a lot of information. From this default view we can quickly see some functionality that would be useful. On the left side of the screen we can see all the defined functions in the binary, such as
Analysing the function calls
The first thing we want to is analyse the main function. We can access the main function in the graph view simply by double clicking the main function in the function listing panel. This reveals the graph view of the main function, normally the graph view would show different branches but the main function simply calls four different functions then exits.
We can see the four different functions, and we can jump to each of their definitions by double clicking them.
In this case I clicked the print flag function since it seems like the obvious choice.
Unfortunately we notice that there is a
This turned out to be a good choice as we can located the string and it’s address very easily.
By pressing x while highlighting this string, or right-clicking and choosing show X-refs (cross-references) we can see were this string is used in the code. In this case, it is used in a mov instruction in the
Looking at this function we can see that it calls puts on our string, and then immediately exits. We can find where this function is referenced by going to the functions panel on the left and pressing x again, or right-clicking and choosing show X-refs. This will lead us closer to our culprit. In this case we can see that the function is only referenced in the set_timer function.
We can now try to understand the functionality of the set timer function to figure out why our program ends abruptly. We can also see cutters branching come into play in this function as it uses a
Now that we have found our culprit function, we can look into how exactly it works. A useful tool when trying to figure out the functionality of some machine code is a decompiler. Cutter actually comes with a C++ rewrite of the Ghidra decompiler, as well as it’s own retdec. We can enable this decompiler view by going to the top bar and clicking Windows -> Decompiler.
This decompiler view allows us to more readily understand the
We cab see that the function has two significant system calls, one to
The two pages I used for this analysis are:
From this I was able to infer three important pieces of information.
So in this case the function will:
So by removing the call to alarm from the binary, alarm_handler should never be hit and the binary should finish running as expected.
Patching the binary with NOPs
When patching the binary it is important to remember that you are changing the binary on disk, and that it is wise to create copies of the binary in it’s original state. What we want to do in this case is change the call to alarm to a NOP (No Operation) instruction so that the binary will not terminate prematurely. We can do this by right clicking the call to alarm in either the disassembly, graph or decompiler view and choosing Edit -> Nop Instruction. I personally recommend doing this through the graph or disassembly view to ensure the correct instruction is NOP’d.
Getting the flag
Now that alarm is never being called, we can shut down cutter and run the binary and we should get the flag.
There are definitely a couple other ways we could have done solved this challenge and some unanswered questions.
All in all Cutter is a solid tool that is built on a well maintained project and it should see continual improvements into the future.
This blog post will provide an overview of the methods available to force NTLM authentication to a rogue server, and capture or relay the credential material. These attacks can be leveraged to escalate privileges within an Active Directory domain environment. I like to look at these attacks as having 3 stages which are:
Stage 1: The Rogue Server
The rogue authentication server can be a compromised endpoint, network implant or Internet based server. This will largely depend on the type of engagement (Red Team, Internal Penetration Test, Phishing, etc) and your current privileges within the network.
Generally speaking, a network implant (which could just be your laptop) will be the easiest and most flexible option. A compromised endpoint will mean dealing with the local firewall and antivirus, however this rarely prevents the attack, but will create extra caveats. An Internet based server will only work if SMB and/or WebDAV outbound is allowed, and will often limit relay options.
There are 4 open source tools that can be used to create a rogue authentication server. These are:
Responder and Impact (specifically the ntlmrelayx script) are written in Python and work best on Linux, Inveigh is written in PowerShell and designed for Windows hosts, InveighZero is written in C# and also designed for Windows hosts. These tools are all parts of toolkits that provide more features than just a rogue authentication server, and I’ll discuss these features in the following sections.
Stage 2: Coerced Authentication
This is the hardest part of the attack, and can often require a good level of creativity. The objective is to coerce a user or machine into authenticating to the rogue authentication server using NTLM authentication, which fortunately for us, is supported by a large number of common protocols (such as SMB, HTTP, RDP, LDAP, etc). The most popular method would be LLMNR/NBN-NS/mDNS poisoning, which I’ll discuss first, but there are an array of good options available.
Link Local Multicast Name Resolution (LLMNR), NetBIOS Name Service (NBT-NS) and Multicast DNS (mDNS) are name resolution services that are built into Windows and enabled by default. LLMNR/NBN-NS/mDNS poisoning attacks leverages the fact that Windows will assume everyone on the network is trusted. This allows an attacker to respond to legitimate queries with the rogue authentication server IP address. Since Windows is generally performing name resolution with the intent of connecting to the server, this causes machines throughout the network to authenticate to the rogue server. All the tools mentioned above expect Impact have name spoofing capabilities built-in.
The same principle discussed in the above name resolution attacks apply to the link layer Address Resolution Protocol (ARP). ARP poisoning can be leveraged to convince targeted victims into thinking that the rogue server is actually the file server, or Domain Controller or any legitimate server that already exists within the network. This can lead to the victim authenticating to the rogue server instead of the legitimate server it initially intended on communicating with.
There are a number of file types that when parsed by Windows Explorer, will cause the download of a remote resource. This remote recourse can be a file that requires NTLM authentication, which Windows will perform automatically and without user interaction. These files types are SCF, LNK and URL. By putting these files into a network share, with a filename that causes them to be displayed at the top of the directory listing for added effect, visitors will automatically authenticate to the rogue server. Mileage may vary as Windows 10 seems to have removed this “feature” for at the very least SCF files.
Phishing or backdooring files for NTLM authentication is another common method. PDF, Microsoft Word and Microsoft Access files can be crafted to cause an NTLM authentication request when opened. These filetypes all supported embedding external content that will be automatically fetched by the respective program. An attacker can leverage this functionality to coerce authenticate requests. I doubt that list is exhaustive and encourage you to research the types of files used on the network for UNC path injection positions.
Security researchers have discovered vulnerabilities within Microsoft software that allows an attacker to force a target machine into performing NTLM authentication with an arbitrary host. The SpoolSample vulnerability by Lee Christensen uses the Print System Remote Protocol (MS-RPRN) interface to requests that a server send updates to an arbitrary host regarding the status of print jobs. This can be used to coerce any machine running the service into authenticating to any machine. This method is so powerful, it can be leveraged to move laterally through Active DIrectory forests.
A ZDI researcher discovered the ability to request Exchange to authenticate to an arbitrary URL over HTTP via the Exchange PushSubscription feature. This attack was called PowerPriv and could often be used to escalate to Domain Admin given the excessive privileges held by the Exchange servers group. Both of these issues were initially considered intended behaviour by Microsoft but later patched due to the security consequences. However, I still come across vulnerable Windows and Exchange servers on internal networks so these methods remain very useful.
There are a few MS-SQL stored procedures that can be leveraged for NTLM authentication. These can be useful when you have the ability to execute SQL queries on an MS-SQL server through compromised credentials, privilege misconfigurations, or an SQL injection vulnerability. The stored procedures xp_dirtree and xp_fileexist can be used with a UNC path to cause the SQL service account to perform an SMB connection and NTLM authentication request.
Stale Network Address Configurations (SNACs) are misconfigurations whereby a server is trying to connect to an IP address that no longer exists within the network. IP aliasing can be used to assign the stale IP address to a network interface on an attacker controlled device to receive the traffic from the misconfigured server. One of the possible outcomes is that the server will connect using a protocol that supports NTLM authentication, and respond to authentication requirements. The tool Eavesarp can help discover these misconfigurations.
By default Windows has IPv6 enabled, and will periodically request an IPv6 address using DHCPv6. If IPv6 is not used within the internal network, and IPv6 has not been disabled, then an attacker can stand-up a DHCPv6 server. The malicious DHCPv6 server can be used to assign link-local IPv6 address and configure the default DNS server. Since IPv6 takes precedence over IPv4, the attacker now controls DNS lookups and can selectively poison queries to force the victims into connecting to a rogue authentication server.
Stage 3.1 : Cracking the Hash
This section requires understanding the basics of the NTLM authentication protocol. NTLM authentication is a challenge-response protocol, whereby a client connecting to a server will be presented with a challenge (in NTLMv1 this would be an 8-byte random number), the client must encrypt the challenge value with their NTLM password hash and return this value to the server for verification. The server is then responsible for validating the encrypted value using its local Security Account Manager (SAM) database or with the help of a Domain Controller. The validation is performed by performing the same encryption operation and checking if the client was correct.
In the event a client performs NTLM authentication with a rogue authentication server, the same process described above takes place. This allows the attacker to obtain a value encrypted with the NTLM hash of the user who authenticated. This key material is an effective hash that can be brute forced to disclose the users plaintext password.
The brute force process reads a password from a wordlist, converts it to an NTLM hash, encrypts the challenge with the NTLM hash (creating a challenge response) and checks if it matches the challenge response received from the victim to determine if the guessed password is correct.
The attacker can control the challenge, which does allow the use of rainbow tables (precomputed lookup tables), but this only works for the older NTLMv1 protocol. In the NTLMv2 implementation, the client chooses part of the challenge which mitigates rainbow table attacks.
Stage 3.2: Relaying the Hash
Since the attacker can choose the challenge, nothing prevents the attacker from retrieving a challenge from a service within the network and having the victim solve it. This allows the attacker to authenticate to an arbitrary service within the network as the victim.
Depending on the victim privileges, this can be leveraged to further compromise machines within the network, gain access to file servers, update Active Directory objects on the Domain Controller, etc.
The advantage of relying is that the credential material never has to be cracked, although you can still perform a brute force to recover the plaintext password as described in 3.1. The only downside is the additional time required to set up the relay server and select appropriate relay targets.
This can be done using Impacket ntlmrelayx, Inveigh-Relay or Responder MultiRelay.
Recommendations and Mitigations
I’m going to break down the recommendations and mitigation into each of the 3 phases of the attack.
Stage 1: The Rogue Server
Stage 2: Coerced Authentication
Stage 3: Relaying and Cracking
The attack leverages weakness in Microsoft protocols and default configurations. Even if all the recommendations and mitigations are applied, some methods such as backdoored files will continue to be effective but the impact should be limited.
On Windows a privilege is the right of an account, such as a user or group account, to perform various system-related operations on the local computer. There are 36 privileges defined in the Privilege Constants although a number are used internally by the operating system. There are a number of privileges that are considered game over, in that, if a user gains access to a game over privilege, they effectively have every privilege and can achieve code execution under the NT AUTHORITY\SYSTEM (referred to as SYSTEM) account.
I wanted to discuss privileges from a practical offensive standpoint. These are actually just my notes on privileges made into a blog post because I needed to clean them up.
If you gain access to (through a misconfiguration, vulnerability in a more privileged process, etc) any of the game over privileges you have completely compromised the local computer.
The privileges SeAssignPrimaryToken, SeCreateToken, SeDebug, SeLoadDriver, SeRestore, SeTakeOwnership and SeTcb are guaranteed to give you SYSTEM. Other privileges could also be abused in specific scenarios and should be investigated.
If you are SYSTEM then regardless of the privileges (even if they have been stripped) you have every privilege:
Starting with Windows 10 Microsoft have removed SeImpersonate and SeAssignPrimaryToken privileges from service processes when they are not required. Task Scheduler can be leveraged to regain the lost privileges:
Often when performing exploits against software running on Windows you will gain code execution within the context of the Local or Network service accounts.
Up until Windows version 1809 (and Server 2019) you could leverage the SeImpersonate or SeAssignPrimaryToken privileges of the service accounts by abusing NTLM local authentication via reflection. This allowed the impersonation or assignment of the SYSTEM token. The most common variations of this method are HotPotato, RottenPotato, RottenPotatoNG and JuicyPotato.
JuicyPotato is the most modern and used method. There are several implementations of juicy-potato that use reflective DLL injection or are implemented as a .NET assembly to avoid dropping files to disk.
On Windows version 1809 (and Server 2019) and later, Microsoft “fixed” the reflected NTLM authentication abuse that allowed JuicyPotato to function. This sparked new research into escalating privileges or regaining the lost permissions. I’m going to list the new methods and research that now exist.
I’ve opted not to go into detail of the methods as all of the write-ups are fantastic and I highly recommend giving them a read. With the number of methods available it would be highly unlikely that the compromise of a service account doesn’t lead to SYSTEM.
socat is a general-purpose networking tool that allows the creation of two bidirectional streams. It has a large amount of support for different protocols and data sources, including OPENSSL, SOCKS4, TCP, UDP, TAP, SCTP and more. When performing a penetration test this tool can be leveraged to bypass basic firewall restrictions and transfer files across the network.
Statically compiled socat
There is a cool project called static-toolbox which provides statically compiled networking and debugging tools. This project includes a statically compiled versions of socat for x86/x86_64 and allows the tool to have a lot more portability between differing Linux distributions and major library versions for a small cost of ~2MB.
Simple Listening Shell
On the client run:
On the attacker machine run
This shell works great, but there are two obvious problems:
We can get around this by using the outbound technique that I will show later.
Simple File Transfer
There are two methods of doing file transfers:
Overall, the better of these two methods is when a client connects to a listening port to download a file, as this is less likely to be blocked by firewalls. To do this you need to run these two commands.
On the attacker:
On the client:
Encrypted Listening Shell
We can generate an encrypted reverse shell with client and server keys to allow only our chosen attacker machine to connect to the server.
socat reverse shell
Sometimes the network will be configured in such a way that only certain ports will be able to host a listening service, such as 80 and 443 on a web host for example. In this case, unless we have sudo privileges, establishing a listening shell with socat is not possible. To mitigate this we can instead forward a shell or service through an outbound connection. We can also establish a PTY shell in a similar fashion
On the attacker machine run:
On the client run:
Forwarding a service through an outbound connection Sometimes we want to be able to access a local service on the machine, for example if we want to access the SSH service running on our host we need to be able to use the ssh command or to be able to use our browser to interact with a local web server. We can achieve this by instead creating a second listening port on the attacker machine that will allows our different programs to connect and interact with the client's service. On the attacker machine we create two listening ports, it will wait for a connection from our client on port 80 and then wait for a suitable
On the client run:
This will allow you to connect to the service (In this case SSH) by connecting to local port 10023.
socat encrypted reverse shell
On the attacker machine we create a listening port, it will wait for a connection from our client on port 80 and then allow us to interact with it from stdin.
On the client machine we need to run:
Forwarding a service through an encrypted outbound connection
After following the key generation steps listed in the encrypted reverse shell section we can wrap our outbound reverse shell in openssl using the following commands.
On the attacker machine we need to run:
On the client machine we need to run:
Finally, we can create a connection by running the final connect command on the attacker machine.
Forwarding packets through a web proxy with socat
Sometimes a service or program will not allow the user to set a HTTP proxy. For example, if you wanted to inspect the HTTP connections a browser is making but the proxy settings are broken. The command to do so follows the general form:
In your browser you would point to
Recently Clément Labro released a blog post about an arbitrary file move vulnerability he discovered. This was CVE-2020-0668 which involved abusing Service Tracing to cause an arbitrary file move with the help of symlinks.
I confirmed the vulnerability using the Google Project Zero symboliclink-testing-tools but wanted to create a standalone executable, that could be easily shipped to a target machine to exploit the CVE. C# seemed like an appropriate language as I could leverage the NtApiDotNet package which had done all the hard work for me.
Writing the code was as simple as following the instructions in the blog post and making sure I understand the mount point and symbolic link trickery. Luckily this has been described by James Forshare in a number of blog posts, and implemented in his API methods NtFile.CreateMountPoint and NtSymbolicLink.Create. The complete proof of concept code can be found on GitHub here.
This post explores how an ASP.NET project incorrectly disclosing its web.config containing static keys allows for remote code execution. The common cases for exploiting this vulnerability would be if the web application has published it’s static machine keys to GitHub, such as with the example project for this post (https://github.com/ozajay0207/EGVC) or if the application has a local file inclusion vulnerability that allows the attacker to obtain a copy of the static keys from the web.config file.
In order to keep track of different sessions, ASP.NET applications use a ViewState that contains serialized application defined data. Due to the nature of serialization, if the user can control and create a valid ViewState, then they can use a deserialization attack to achieve remote code execution on the host.
In order to mitigate this potential attack ASP.NET applications can perform HMAC signing of the ViewState to verify the authenticity of the object. Another option is using encryption with a secret key to prevent reading or modification of its contents. Keeping these keys secret is paramount in preventing ViewState deserialization attacks and remote code execution.
These mitigations rely on each application utilising uniquely generated validation and decryption keys, which is not always the case. Recently, CVE-2020-688 exposed Microsoft for including static validation and decryption keys in the Microsoft Exchange Server’s control panel. The same keys were generated once and shared among every exchange installation allowing anyone with a copy of the server to recover and misuse these key values.
To demonstrate this attack, a proof of concept will be performed for a public GitHub project that contained this vulnerability. Figure 1 is the web.config from the chosen project and contains two security issues. Firstly, the validation and decryption key are hard coded and secondly, the ViewState encryption mode has been disabled.
A successful attack requires not only the validation key, but also a page on the website that uses a ViewState. In this case the website has a registration page that includes various text entries and controls; a perfect candidate for using ViewState. In the registration page’s source code there are two hidden elements that include the page’s ViewState and ViewState Generator.
Now that the three required pieces of information have been recovered, a payload can be generated using ysoserial.net. The malicious payload will execute an arbitrary command, in this case a simple PowerShell web request to a controlled endpoint, is used so that the code execution can be verified.
The tool ysoserial.net creates a payload that is base64 encoded but supplying this directly to the server in a request will cause parsing errors. This occurs because the base64 standard includes some symbols, such as the equals sign, that will be misinterpreted in a HTTP request. To remedy this the payload must be URL encoded. With this encoding the necessary symbols will be correctly interpreted by the ASP application.
To perform the attack the default packet HTTP POST from the registration form was captured into BurpSuite, and the __VIEWSTATE variable was replaced with the malicious ViewState generated by ysoserial.net. Once the request is sent to the server the PowerShell command is executed, and a corresponding GET request is made to our controlled endpoint.
From here it is straightforward for an attacker to modify the command to download and execute a malicious PowerShell script and create a reverse shell.
